Steelspan Pallet Racking - H3658 x D1220mm - Add On Bay
Discounts applied in cart across Cantilever Racking and Pallet Racking. Calculate shipping at checkout.
Shipping Estimator
Not close to you? No problem we ship Australia wide.
Description
Steelspan Pallet Racking is certified in Australia to Australian Standard 4084-2023.
Beam box height: 80/100/120/140mm
Beam box depth 50mm
NOTE: add 90mm to width per End Frame. Full Bays have two End Frames, whereas Add On Bays have one End Frame and are designed to extend Full Bays.
Pitch: 76.2mm
Total Bay Capacity: Up to 8400kg
Beam Locking Pins included
Concrete Anchors included
Finish:
- Frame: Pre Galvanised
- Beam: Powder Coated - Safety Yellow
Product Brochure - Warehouse Storage Systems (PDF)
*The maximum capacities shown are dependant on the racking design configuration. Always consult with the manufacturer before determining signage load capacities. Steelspan Storage Systems will not warrant or accept liability for racking designed and installed without its consultation and certification.
Height: 3658mm
Depth: 1220mm
Width is based on Beam selected. See dimensions guide below.
